Please send RFQ , we will respond immediately.
| Part Number | PNP10VJT-91-1R | PNP10VJT-91-1R2 | PNP10VJT-91-1R5 | PNP10VJT-91-1R8 | PNP10VJT-91-3R | PNP10VJT-91-51R | PNP10VJT-91-91R | PNP10VJT-91-10R | PNP10VJT-91-12R | PNP10VJT-91-15R | PNP10VJT-91-18R | PNP10VJT-91-1K |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO | YAGEO |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Resistance | 1 Ohms | 1.2 Ohms | 1.5 Ohms | 1.8 Ohms | 3 Ohms | 51 Ohms | 91 Ohms | 10 Ohms | 12 Ohms | 15 Ohms | 18 Ohms | 1 kOhms |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
| Power (Watts) | 10W | 10W | 10W | 10W | 10W | 10W | 10W | 10W | 10W | 10W | 10W | 10W |
| Composition | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound |
| Features | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety | Flame Retardant Coating, Safety |
| Temperature Coefficient | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | - | - | - | - | - | - |
| Operating Temperature | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C | -40°C ~ 200°C |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial |
| Supplier Device Package | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) | 0.315" Dia x 1.732" L (8.00mm x 44.00mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - | - | - | - | - |
| Number of Terminations | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Failure Rate | - | - | - | - | - | - | - | - | - | - | - | - |
