| Part Number | XCZU2CG-1SFVA625E | XCZU2EG-1SFVA625E | XCZU2CG-1SFVA625I | XCZU2CG-2SFVA625E | XCZU3CG-1SFVA625E | XCZU1CG-1SFVA625E |
|---|---|---|---|---|---|---|
| Manufacturer | AMD Xilinx | AMD Xilinx | AMD Xilinx | AMD Xilinx | AMD Xilinx | AMD Xilinx |
| Product Status | Active | Active | Active | Active | Active | Active |
| Architecture | MCU, FPGA | MCU, FPGA | MCU, FPGA | MCU, FPGA | MCU, FPGA | MPU, FPGA |
| Core Processor | Dual ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™ | Dual ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™ | Dual ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™ | Dual ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™ | Dual ARM® Cortex®-A53 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5 with CoreSight™ | |
| Flash Size | - | - | - | - | - | - |
| RAM Size | 256KB | 256KB | 256KB | 256KB | 256KB | 256KB |
| Peripherals | DMA, WDT | DMA, WDT | DMA, WDT | DMA, WDT | DMA, WDT | DMA, WDT |
| Connectivity | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | - |
| Speed | 500MHz, 1.2GHz | 500MHz, 600MHz, 1.2GHz | 500MHz, 1.2GHz | 533MHz, 1.3GHz | 500MHz, 1.2GHz | 500MHz, 1.2GHz |
| Primary Attributes | Zynq®UltraScale+™ FPGA, 103K+ Logic Cells | Zynq®UltraScale+™ FPGA, 103K+ Logic Cells | Zynq®UltraScale+™ FPGA, 103K+ Logic Cells | Zynq®UltraScale+™ FPGA, 103K+ Logic Cells | Zynq®UltraScale+™ FPGA, 154K+ Logic Cells | - |
| Operating Temperature | 0°C ~ 100°C (TJ) | 0°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | 0°C ~ 100°C (TJ) | 0°C ~ 100°C (TJ) | 0°C ~ 100°C (TJ) |
| Package / Case | 625-BFBGA, FCBGA | 625-BFBGA, FCBGA | 625-BFBGA, FCBGA | 625-BFBGA, FCBGA | 625-BFBGA, FCBGA | 625-BFBGA, FCBGA |
| Supplier Device Package | 625-FCBGA (21x21) | 625-FCBGA (21x21) | 625-FCBGA (21x21) | 625-FCBGA (21x21) | 625-FCBGA (21x21) | 625-FCBGA (21x21) |
