Please send RFQ , we will respond immediately.
| Part Number | XCVM1802-1LLIVSVA2197 | XCVM1802-1LSIVSVA2197 | XCVM1802-1MLIVSVA2197 | XCVC1802-1LLIVSVA2197 |
|---|---|---|---|---|
| Manufacturer | AMD Xilinx | AMD Xilinx | AMD Xilinx | AMD Xilinx |
| Product Status | Active | Active | Active | Active |
| Architecture | MPU, FPGA | MPU, FPGA | MPU, FPGA | MPU, FPGA |
| Core Processor | Dual ARM® Cortex®-A72 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5F with CoreSight™ | Dual ARM® Cortex®-A72 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5F with CoreSight™ | Dual ARM® Cortex®-A72 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5F with CoreSight™ | Dual ARM® Cortex®-A72 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5F with CoreSight™ |
| Flash Size | - | - | - | - |
| RAM Size | 256KB | 256KB | 256KB | 256KB |
| Peripherals | DDR, DMA, PCIe | DDR, DMA, PCIe | DDR, DMA, PCIe | DDR, DMA, PCIe |
| Connectivity | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SPI, UART/USART, USB OTG |
| Speed | 400MHz, 1GHz | 400MHz, 1GHz | 600MHz, 1.3GHz | 400MHz, 1GHz |
| Primary Attributes | Versal™ Prime FPGA, 1.9M Logic Cells | Versal™ Prime FPGA, 1.9M Logic Cells | Versal™ Prime FPGA, 1.9M Logic Cells | Versal™ AI Core FPGA, 1.5M Logic Cells |
| Operating Temperature | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) | -40°C ~ 100°C (TJ) |
| Package / Case | 2197-BFBGA, FCBGA | 2197-BFBGA, FCBGA | 2197-BFBGA, FCBGA | 2197-BFBGA, FCBGA |
| Supplier Device Package | 2197-FCBGA (45x45) | 2197-FCBGA (45x45) | 2197-FCBGA (45x45) | 2197-FCBGA (45x45) |
