| Part Number | T24C106K125USS | T22C106K125USS | T24C106K125CSS |
|---|---|---|---|
| Manufacturer | Vishay Sprague | Vishay Sprague | Vishay Sprague |
| Product Status | Active | Active | Active |
| Capacitance | 10 µF | 10 µF | 10 µF |
| Tolerance | ±10% | ±10% | ±10% |
| Voltage - Rated | 125 V | 125 V | 125 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | 5.5Ohm @ 120Hz | 5.5Ohm @ 120Hz | 5.5Ohm @ 120Hz |
| Operating Temperature | -55°C ~ 200°C | -55°C ~ 125°C | -55°C ~ 85°C |
| Lifetime @ Temp. | 2000 Hrs @ 200°C | 2000 Hrs @ 125°C | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Size / Dimension | 0.303" L x 0.280" W (7.70mm x 7.10mm) | 0.303" L x 0.280" W (7.70mm x 7.10mm) | 0.303" L x 0.280" W (7.70mm x 7.10mm) |
| Height - Seated (Max) | 0.299" (7.60mm) | 0.299" (7.60mm) | 0.299" (7.60mm) |
| Lead Spacing | - | - | - |
| Manufacturer Size Code | C | C | C |
| Ratings | - | - | - |
| Features | Wet Tantalum | Wet Tantalum | Wet Tantalum |
| Failure Rate | - | - | S (0.001%) |
