Please send RFQ , we will respond immediately.
| Part Number | M39006/22-0505 | M39006/22-0525 | M39006/22-0565 | M39006/22-0005 | M39006/22-0105 | M39006/22-0205 | M39006/22-0305 | M39006/22-0405 |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Vishay Sprague | Vishay Sprague | Vishay Sprague | EXXELIA | KYOCERA AVX | EXXELIA | EXXELIA | EXXELIA |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active |
| Capacitance | 33 µF | 22 µF | 10 µF | 68 µF | 15 µF | 3.6 µF | 22 µF | 4.7 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage - Rated | 15 V | 25 V | 50 V | 6 V | 30 V | 125 V | 25 V | 100 V |
| Type | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed | Hermetically Sealed |
| ESR (Equivalent Series Resistance) | - | - | - | 3.16Ohm | 4.42Ohm | 9.95Ohm | 3.98Ohm | 8.47Ohm |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Lifetime @ Temp. | - | - | - | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.219" Dia x 0.515" L (5.56mm x 13.08mm) | 0.219" Dia x 0.515" L (5.56mm x 13.08mm) | 0.219" Dia x 0.515" L (5.56mm x 13.08mm) | 0.219" Dia x 0.453" L (5.56mm x 11.51mm) | - | 0.219" Dia x 0.453" L (5.56mm x 11.51mm) | 0.219" Dia x 0.453" L (5.56mm x 11.51mm) | 0.219" Dia x 0.453" L (5.56mm x 11.51mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - |
| Lead Spacing | - | - | - | - | - | - | - | - |
| Manufacturer Size Code | T1 | T1 | T1 | T1 | - | T1 | T1 | T1 |
| Ratings | - | - | - | - | - | - | - | - |
| Features | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum | High Reliability, Wet Tantalum |
| Failure Rate | R (0.01%) | R (0.01%) | R (0.01%) | M (1%) | M (1%) | M (1%) | P (0.1%) | P (0.1%) |
