| Part Number | IHTH1500MZEB2R7M5A | IHTH1500MZEB4R7M5A | IHTH1500MZEB2R2M5A |
|---|---|---|---|
| Manufacturer | Vishay Dale | Vishay Dale | Vishay Dale |
| Product Status | Active | Active | Active |
| Type | - | - | - |
| Material - Core | Metal Composite | Metal Composite | Metal Composite |
| Inductance | 2.7 µH | 4.7 µH | 2.2 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 87.3 A | 60.6 A | 81.7 A |
| Current - Saturation (Isat) | 96.7A | 90.1A | 111.4A |
| Shielding | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 0.51mOhm Max | 1.19mOhm Max | 0.54mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | 14.1MHz | 9.2MHz | 14.7MHz |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 155°C | -55°C ~ 155°C | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial, Vertical Cylinder, 4 Leads | Radial, Vertical Cylinder, 4 Leads | Radial, Vertical Cylinder, 4 Leads |
| Supplier Device Package | Radial | Radial | Radial |
| Size / Dimension | 1.500" Dia (38.10mm) | 1.500" Dia (38.10mm) | 1.500" Dia (38.10mm) |
| Height - Seated (Max) | 0.502" (12.75mm) | 0.502" (12.76mm) | 0.502" (12.76mm) |
