| Part Number | IHSM3825ER5R6L | IHSM4825ER5R6L |
|---|---|---|
| Manufacturer | Vishay Dale | Vishay Dale |
| Product Status | Active | Active |
| Type | - | - |
| Material - Core | Ferrite | Ferrite |
| Inductance | 5.6 µH | 5.6 µH |
| Tolerance | ±15% | ±15% |
| Current Rating (Amps) | 2.08 A | 3.8 A |
| Current - Saturation (Isat) | 1.79A | 1.9A |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 91mOhm Max | 51mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 1 kHz | 1 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | 0.440" L x 0.250" W (11.18mm x 6.35mm) | 0.540" L x 0.250" W (13.72mm x 6.35mm) |
| Height - Seated (Max) | 0.225" (5.72mm) | 0.225" (5.72mm) |
