| Part Number | IHLP1212BZEV3R3M01 | IHLP1212BZEV3R3MA1 |
|---|---|---|
| Manufacturer | Vishay Dale | Vishay Dale |
| Product Status | Active | Active |
| Type | - | - |
| Material - Core | - | Metal Composite |
| Inductance | - | 3.3 µH |
| Tolerance | - | ±20% |
| Current Rating (Amps) | - | 3.3 A |
| Current - Saturation (Isat) | - | 4.5A |
| Shielding | - | Shielded |
| DC Resistance (DCR) | - | 98.48mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | 41.6MHz |
| Ratings | - | AEC-Q200 |
| Operating Temperature | - | -55°C ~ 125°C |
| Inductance Frequency - Test | - | 100 kHz |
| Features | - | - |
| Mounting Type | - | Surface Mount |
| Package / Case | - | Nonstandard |
| Supplier Device Package | - | - |
| Size / Dimension | - | 0.140" L x 0.130" W (3.56mm x 3.30mm) |
| Height - Seated (Max) | - | 0.079" (2.00mm) |
