| Part Number | IHD1ER5R6L | IHD1EB5R6L |
|---|---|---|
| Manufacturer | Vishay Dale | Vishay Dale |
| Product Status | Active | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite |
| Inductance | 5.6 µH | 5.6 µH |
| Tolerance | ±15% | ±15% |
| Current Rating (Amps) | 3.2 A | 3.2 A |
| Current - Saturation (Isat) | 3A | 3A |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 24mOhm Max | 24mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C |
| Inductance Frequency - Test | 1 kHz | 1 kHz |
| Features | - | - |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Axial |
| Supplier Device Package | - | - |
| Size / Dimension | 0.270" Dia x 0.700" L (6.85mm x 17.78mm) | 0.270" Dia x 0.700" L (6.85mm x 17.78mm) |
| Height - Seated (Max) | - | - |
