| Part Number | IFLR4027EZERR10M01 | IFLR4027EZERR15M01 |
|---|---|---|
| Manufacturer | Vishay Dale | Vishay Dale |
| Product Status | Active | Active |
| Type | - | - |
| Material - Core | - | - |
| Inductance | 100 nH | 155 nH |
| Tolerance | ±20% | ±20% |
| Current Rating (Amps) | 50 A | 50 A |
| Current - Saturation (Isat) | 70A | 40A |
| Shielding | Shielded | Shielded |
| DC Resistance (DCR) | 0.42mOhm Max | 0.42mOhm Max |
| Q @ Freq | - | - |
| Frequency - Self Resonant | - | - |
| Ratings | - | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz | 100 kHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 2-SMD, J-Lead | 2-SMD, J-Lead |
| Supplier Device Package | - | - |
| Size / Dimension | 0.276" L x 0.402" W (7.00mm x 10.20mm) | 0.276" L x 0.402" W (7.00mm x 10.20mm) |
| Height - Seated (Max) | 0.197" (5.00mm) | 0.197" (5.00mm) |
