UCC27527DSDT
  • Share:

Texas Instruments UCC27527DSDT

Manufacturer No:
UCC27527DSDT
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
UCC27527DSDT Datasheet
ECAD Model:
-
Description:
IC GATE DRVR LOW-SIDE 8SON
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Driven Configuration:Low-Side
Channel Type:Independent
Number of Drivers:2
Gate Type:IGBT, N-Channel MOSFET
Voltage - Supply:4.5V ~ 18V
Logic Voltage - VIL, VIH:-
Current - Peak Output (Source, Sink):5A, 5A
Input Type:Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap):-
Rise / Fall Time (Typ):7ns, 6ns
Operating Temperature:-40°C ~ 140°C (TJ)
Mounting Type:Surface Mount
Package / Case:8-WDFN Exposed Pad
Supplier Device Package:8-SON (3x3)
0 Remaining View Similar

In Stock

$2.85
167

Please send RFQ , we will respond immediately.

Similar Products

Part Number UCC27527DSDT UCC27528DSDT   UCC27523DSDT   UCC27524DSDT   UCC27525DSDT   UCC27526DSDT   UCC27527DSDR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Active Active Active Active Active Active Active
Driven Configuration Low-Side Low-Side Low-Side Low-Side Low-Side Low-Side Low-Side
Channel Type Independent Independent Independent Independent Independent Independent Independent
Number of Drivers 2 2 2 2 2 2 2
Gate Type IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET IGBT, N-Channel MOSFET
Voltage - Supply 4.5V ~ 18V 4.5V ~ 18V 4.5V ~ 18V 4.5V ~ 18V 4.5V ~ 18V 4.5V ~ 18V 4.5V ~ 18V
Logic Voltage - VIL, VIH - - 1V, 2.3V 1V, 2.3V 1V, 2.3V 1V, 2.3V -
Current - Peak Output (Source, Sink) 5A, 5A 5A, 5A 5A, 5A 5A, 5A 5A, 5A 5A, 5A 5A, 5A
Input Type Inverting, Non-Inverting Non-Inverting Inverting Non-Inverting Inverting, Non-Inverting Inverting, Non-Inverting Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap) - - - - - - -
Rise / Fall Time (Typ) 7ns, 6ns 7ns, 6ns 7ns, 6ns 7ns, 6ns 7ns, 6ns 7ns, 6ns 7ns, 6ns
Operating Temperature -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ) -40°C ~ 140°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 8-WDFN Exposed Pad 8-WDFN Exposed Pad 8-WDFN Exposed Pad 8-WDFN Exposed Pad 8-WDFN Exposed Pad 8-WDFN Exposed Pad 8-WDFN Exposed Pad
Supplier Device Package 8-SON (3x3) 8-SON (3x3) 8-SON (3x3) 8-SON (3x3) 8-SON (3x3) 8-SON (3x3) 8-SON (3x3)
