| Part Number | UA78L08CPK | UA78L05CPK | UA78L08ACPK |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active |
| Output Configuration | - | Positive | Positive |
| Output Type | - | Fixed | Fixed |
| Number of Regulators | - | 1 | 1 |
| Voltage - Input (Max) | - | 20V | 23V |
| Voltage - Output (Min/Fixed) | - | 5V | 8V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | - | 1.7V @ 40mA | 1.7V @ 40mA |
| Current - Output | - | 100mA | 100mA |
| Current - Quiescent (Iq) | - | - | - |
| Current - Supply (Max) | - | - | - |
| PSRR | - | 49dB (120Hz) | 46dB (120Hz) |
| Control Features | - | - | - |
| Protection Features | - | Over Current, Over Temperature, Reverse Polarity, Short Circuit | Over Current, Over Temperature, Reverse Polarity, Short Circuit |
| Operating Temperature | - | 0°C ~ 125°C | 0°C ~ 125°C |
| Mounting Type | - | Surface Mount | Surface Mount |
| Package / Case | - | TO-243AA | TO-243AA |
| Supplier Device Package | - | SOT-89-3 | SOT-89-3 |
