| Part Number | TPS7B8233QDGNRQ1 | TPS7B8133QDGNRQ1 |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| Output Configuration | Positive | Positive |
| Output Type | Fixed | Fixed |
| Number of Regulators | 1 | 1 |
| Voltage - Input (Max) | 40V | 40V |
| Voltage - Output (Min/Fixed) | 3.3V, 5V | 3.3V |
| Voltage - Output (Max) | - | - |
| Voltage Dropout (Max) | 1.25V @ 300mA, 1V @ 300mA | 0.65V @ 150mA |
| Current - Output | 300mA | 150mA |
| Current - Quiescent (Iq) | 5 µA | 3.5 µA |
| Current - Supply (Max) | - | 6.5 µA |
| PSRR | 60dB (100Hz) | 60dB (100Hz) |
| Control Features | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 8-HVSSOP | 8-HVSSOP |
