TPS70802PWPRG4
  • Share:

Texas Instruments TPS70802PWPRG4

Manufacturer No:
TPS70802PWPRG4
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
TPS70802PWPRG4 Datasheet
ECAD Model:
-
Description:
IC REG LINEAR POS ADJ 20HTSSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Configuration:Positive
Output Type:Adjustable
Number of Regulators:2
Voltage - Input (Max):6V
Voltage - Output (Min/Fixed):1.22V
Voltage - Output (Max):5.5V
Voltage Dropout (Max):0.14V @ 250mA, -
Current - Output:250mA, 125mA
Current - Quiescent (Iq):230 µA
Current - Supply (Max):-
PSRR:60dB (1KHz), 50dB (1kHz)
Control Features:Enable, Power Good, Reset, Sequencing
Protection Features:Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Operating Temperature:-40°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:20-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package:20-HTSSOP
0 Remaining View Similar

In Stock

-
76

Please send RFQ , we will respond immediately.

Similar Products

Part Number TPS70802PWPRG4 TPS70202PWPRG4   TPS70302PWPRG4   TPS70802PWPG4
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Obsolete Discontinued at Digi-Key Discontinued at Digi-Key Discontinued at Digi-Key
Output Configuration Positive Positive Positive Positive
Output Type Adjustable Adjustable Adjustable Adjustable
Number of Regulators 2 2 2 2
Voltage - Input (Max) 6V 6V 6V 6V
Voltage - Output (Min/Fixed) 1.22V 1.22V 1.22V 1.22V
Voltage - Output (Max) 5.5V 5.5V 5.5V 5.5V
Voltage Dropout (Max) 0.14V @ 250mA, - 0.28V @ 500mA, - 0.25V @ 1A, - 0.14V @ 250mA, -
Current - Output 250mA, 125mA 500mA, 250mA 1A, 2A 250mA, 125mA
Current - Quiescent (Iq) 230 µA 190 µA 250 µA 230 µA
Current - Supply (Max) - 230 µA - -
PSRR 60dB (1KHz), 50dB (1kHz) 60dB (1kHz) 65dB (1kHz), 60dB (1kHz) 60dB (1KHz), 50dB (1kHz)
Control Features Enable, Power Good, Reset, Sequencing Enable, Power Good, Reset, Sequencing Enable, Power Good, Reset, Sequencing Enable, Power Good, Reset, Sequencing
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Operating Temperature -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C -40°C ~ 125°C
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 20-PowerTSSOP (0.173", 4.40mm Width) 20-PowerTSSOP (0.173", 4.40mm Width) 24-TSSOP (0.173", 4.40mm Width) Exposed Pad 20-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package 20-HTSSOP 20-HTSSOP 24-HTSSOP 20-HTSSOP
