Please send RFQ , we will respond immediately.
| Part Number | TPS610995YFFR | TPS610995YFFT | TPS610997YFFR | TPS61099YFFR | TPS610996YFFR | TPS610992YFFR | TPS610993YFFR | TPS610994YFFR |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active |
| Function | Step-Up | Step-Up | Step-Up | Step-Up | Step-Up | Step-Up | Step-Up | Step-Up |
| Output Configuration | Positive | Positive | Positive | Positive | Positive | Positive | Positive | Positive |
| Topology | Boost | Boost | Boost | Boost | Boost | Boost | Boost | Boost |
| Output Type | Fixed | Fixed | Fixed | Adjustable | Fixed | Fixed | Fixed | Fixed |
| Number of Outputs | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Voltage - Input (Min) | 0.7V | 0.7V | 0.7V | 0.7V | 0.7V | 0.7V | 0.7V | 0.7V |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 3.6V | 3.6V | 5V | 1.8V | 4.5V | 2.5V | 3V | 3.3V |
| Voltage - Output (Max) | - | - | - | 5.5V | - | - | - | - |
| Current - Output | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) | 800mA (Switch) |
| Frequency - Switching | - | - | - | - | - | - | - | - |
| Synchronous Rectifier | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA | 6-UFBGA, DSBGA |
| Supplier Device Package | 6-DSBGA | 6-DSBGA | 6-DSBGA | 6-DSBGA | 6-DSBGA | 6-DSBGA | 6-DSBGA | 6-DSBGA |
