TPS40004DGQ
  • Share:

Texas Instruments TPS40004DGQ

Manufacturer No:
TPS40004DGQ
Manufacturer:
Texas Instruments
Package:
Tube
Datasheet:
TPS40004DGQ Datasheet
ECAD Model:
-
Description:
IC REG CTRLR BUCK 10MSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Down
Output Configuration:Positive
Topology:Buck
Number of Outputs:1
Output Phases:1
Voltage - Supply (Vcc/Vdd):2.25V ~ 5.5V
Frequency - Switching:300kHz
Duty Cycle (Max):94%
Synchronous Rectifier:Yes
Clock Sync:No
Serial Interfaces:-
Control Features:Current Limit, Enable, Soft Start
Operating Temperature:-40°C ~ 85°C (TA)
Mounting Type:Surface Mount
Package / Case:10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package:10-HVSSOP
0 Remaining View Similar

In Stock

$1.75
453

Please send RFQ , we will respond immediately.

Similar Products

Part Number TPS40004DGQ TPS40007DGQ   TPS40009DGQ   TPS40004DGQR   TPS40005DGQ   TPS40000DGQ   TPS40001DGQ   TPS40002DGQ   TPS40003DGQ
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Obsolete Active Active Not For New Designs Obsolete Active Not For New Designs Not For New Designs Not For New Designs
Output Type Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver Transistor Driver
Function Step-Down Step-Down Step-Down Step-Down Step-Down Step-Down Step-Down Step-Down Step-Down
Output Configuration Positive Positive Positive Positive Positive Positive Positive Positive Positive
Topology Buck Buck Buck Buck Buck Buck Buck Buck Buck
Number of Outputs 1 1 1 1 1 1 1 1 1
Output Phases 1 1 1 1 1 1 1 1 1
Voltage - Supply (Vcc/Vdd) 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V 2.25V ~ 5.5V
Frequency - Switching 300kHz 300kHz 600kHz 300kHz 600kHz 300kHz 300kHz 600kHz 600kHz
Duty Cycle (Max) 94% 94% 93% 94% 93% 94% 94% 93% 93%
Synchronous Rectifier Yes Yes Yes Yes Yes Yes Yes Yes Yes
Clock Sync No No No No No No No No No
Serial Interfaces - - - - - - - - -
Control Features Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start Current Limit, Enable, Soft Start
Operating Temperature -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width) 10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP 10-HVSSOP
