| Part Number | TPS22934YZVT | TPS22934YZVR |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| Switch Type | General Purpose | General Purpose |
| Number of Outputs | 1 | 1 |
| Ratio - Input:Output | 1:1 | 1:1 |
| Output Configuration | High Side | High Side |
| Output Type | P-Channel | P-Channel |
| Interface | On/Off | On/Off |
| Voltage - Load | 1.5V ~ 3.6V | 1.5V ~ 3.6V |
| Voltage - Supply (Vcc/Vdd) | Not Required | Not Required |
| Current - Output (Max) | 1A | 1A |
| Rds On (Typ) | 63mOhm | 63mOhm |
| Input Type | Non-Inverting | Non-Inverting |
| Features | Load Discharge, Slew Rate Controlled | Load Discharge, Slew Rate Controlled |
| Fault Protection | UVLO | UVLO |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 4-DSBGA (0.88x0.88) | 4-DSBGA (0.88x0.88) |
| Package / Case | 4-XFBGA, DSBGA | 4-XFBGA, DSBGA |
