| Part Number | TMS320DM8167SCYG | TMS320DM8167SCYG2 | TMS320DM8168SCYG | TMS320DM8167SCYG4 | TMS320DM8165SCYG | TMS320DM8166SCYG |
|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Discontinued at Digi-Key | Active | Discontinued at Digi-Key |
| Type | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) |
| Interface | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB | EBI/EMI, Ethernet, I²C, McASP, McBSP, PCI, Serial ATA, SD/SDIO, SPI, UART, USB |
| Clock Rate | 800MHz DSP, 1.0GHz ARM® | 1GHz DSP, 1.2GHz ARM® | 800MHz DSP, 1.0GHz ARM® | 1.125GHz DSP, 1.35GHz ARM® | 800MHz DSP, 1.0GHz ARM® | 800MHz DSP, 1.0GHz ARM® |
| Non-Volatile Memory | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) |
| On-Chip RAM | 1.5MB | 1.5MB | 1.5MB | 1.5MB | 1.5MB | 1.5MB |
| Voltage - I/O | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V |
| Voltage - Core | 1.00V | 1.00V | 1.00V | 1.00V | 1.00V | 1.00V |
| Operating Temperature | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 1031-BFBGA, FCBGA | 1031-BFBGA, FCBGA | 1031-BFBGA, FCBGA | 1031-BFBGA, FCBGA | 1031-BFBGA, FCBGA | 1031-BFBGA, FCBGA |
| Supplier Device Package | 1031-FCBGA (25x25) | 1031-FCBGA (25x25) | 1031-FCBGA (25x25) | 1031-FCBGA (25x25) | 1031-FCBGA (25x25) | 1031-FCBGA (25x25) |
