| Part Number | TMS320DM8147BCYE0 | TMS320DM8147SCYE0 | TMS320DM8147BCYE1 | TMS320DM8148BCYE0 | TMS320DM8147BCYE2 | TMS320DM8127BCYE0 |
|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Active | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) | Digital Media System-on-Chip (DMSoC) |
| Interface | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB | CAN, Ethernet, I²C, McASP, McBSP, MMC/SD, SPI, UART, USB |
| Clock Rate | 600MHz DSP, 720MHz ARM® | 600MHz DSP, 720MHz ARM® | 700MHz DSP, 1GHz ARM® | 600MHz DSP, 720MHz ARM® | 700MHz DSP, 1GHz ARM® | 500MHz DSP, 600MHz ARM® |
| Non-Volatile Memory | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) | ROM (48kB) |
| On-Chip RAM | 1.08MB | 1.08MB | 1.08MB | 1.08MB | 1.08MB | 832kB |
| Voltage - I/O | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V | 1.5V, 1.8V, 3.3V |
| Voltage - Core | 1.1V, 1.2V, 1.35V | 1.1V, 1.2V, 1.35V | 1.1V, 1.2V, 1.35V | 1.1V, 1.2V, 1.35V | 1.1V, 1.2V, 1.35V | 1.15V |
| Operating Temperature | 0°C ~ 90°C (TJ) | 0°C ~ 90°C (TJ) | 0°C ~ 90°C (TJ) | 0°C ~ 90°C (TJ) | 0°C ~ 90°C (TJ) | 0°C ~ 90°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 684-BFBGA, FCBGA | 684-BFBGA, FCBGA | 684-BFBGA, FCBGA | 684-BFBGA, FCBGA | 684-BFBGA, FCBGA | 684-BFBGA, FCBGA |
| Supplier Device Package | 684-FCBGA (23x23) | 684-FCBGA (23x23) | 684-FCBGA (23x23) | 684-FCBGA (23x23) | 684-FCBGA (23x23) | 684-FCBGA (23x23) |
