| Part Number | TLV9061IDPWR | TLV9001IDPWR | TLV9041IDPWR | TLV9051IDPWR |
|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Active |
| Amplifier Type | CMOS | CMOS | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 | 1 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Push-Pull, Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 6.5V/µs | 2V/µs | 0.2V/µs | 15V/µs |
| Gain Bandwidth Product | 10 MHz | 1 MHz | 350 kHz | 5 MHz |
| -3db Bandwidth | - | - | - | - |
| Current - Input Bias | 0.5 pA | 5 pA | 1 pA | 2 pA |
| Voltage - Input Offset | 300 µV | 400 µV | 600 µV | 330 µV |
| Current - Supply | 538µA | 60µA | 10µA | 330µA |
| Current - Output / Channel | 50 mA | 40 mA | 40 mA | 50 mA |
| Voltage - Supply Span (Min) | 1.8 V | 1.8 V | 1.2 V | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V | 5.5 V | 5.5 V | 5.5 V |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 5-XFDFN Exposed Pad | 5-XFDFN Exposed Pad | 5-XFDFN Exposed Pad | 5-XFDFN Exposed Pad |
| Supplier Device Package | 5-X2SON (0.8x0.8) | 5-X2SON (0.8x0.8) | 5-X2SON (0.8x0.8) | 5-X2SON (0.8x0.8) |
