TLV74315PDQNR
  • Share:

Texas Instruments TLV74315PDQNR

Manufacturer No:
TLV74315PDQNR
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
TLV74315PDQNR Datasheet
ECAD Model:
-
Description:
IC REG LINEAR 1.5V 300MA 4X2SON
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Configuration:Positive
Output Type:Fixed
Number of Regulators:1
Voltage - Input (Max):5.5V
Voltage - Output (Min/Fixed):1.5V
Voltage - Output (Max):-
Voltage Dropout (Max):0.4V @ 300mA
Current - Output:300mA
Current - Quiescent (Iq):60 µA
Current - Supply (Max):-
PSRR:68dB ~ 28dB (100Hz ~ 100kHz)
Control Features:Enable
Protection Features:Current Limit, Thermal Shutdown, UVLO
Operating Temperature:-40°C ~ 125°C (TJ)
Mounting Type:Surface Mount
Package / Case:4-XDFN Exposed Pad
Supplier Device Package:4-X2SON (1x1)
0 Remaining View Similar

In Stock

$0.08
6,925

Please send RFQ , we will respond immediately.

Similar Products

Part Number TLV74315PDQNR TLV74318PDQNR   TLV74325PDQNR   TLV73315PDQNR   TLV74115PDQNR   TLV74215PDQNR   TLV74310PDQNR   TLV74311PDQNR   TLV74312PDQNR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Active Active Active Active Active Active Active Active Active
Output Configuration Positive Positive Positive Positive Positive Positive Positive Positive Positive
Output Type Fixed Fixed Fixed Fixed Fixed Fixed Fixed Fixed Fixed
Number of Regulators 1 1 1 1 1 1 1 1 1
Voltage - Input (Max) 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V
Voltage - Output (Min/Fixed) 1.5V 1.8V 2.5V 1.5V 1.5V 1.5V 1V 1.1V 1.2V
Voltage - Output (Max) - - - - - - - - -
Voltage Dropout (Max) 0.4V @ 300mA 0.3V @ 300mA 0.29V @ 300mA 0.4V @ 300mA 1.02V @ 150mA - - 0.48V @ 300mA 0.45V @ 300mA
Current - Output 300mA 300mA 300mA 300mA 150mA 200mA 300mA 300mA 300mA
Current - Quiescent (Iq) 60 µA 60 µA 60 µA 60 µA 50 µA 50 µA 60 µA 60 µA 60 µA
Current - Supply (Max) - - - - 75 µA - - - -
PSRR 68dB ~ 28dB (100Hz ~ 100kHz) 68dB ~ 28dB (100Hz ~ 100kHz) 68dB ~ 28dB (100Hz ~ 100kHz) 68dB ~ 28dB (100Hz ~ 100kHz) 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 55dB (100Hz ~ 1MHz) 68dB ~ 28dB (100Hz ~ 100kHz) 68dB ~ 28dB (100Hz ~ 100kHz) 68dB ~ 28dB (100Hz ~ 100kHz)
Control Features Enable Enable Enable Enable Enable Enable Enable Enable Enable
Protection Features Current Limit, Thermal Shutdown, UVLO Current Limit, Thermal Shutdown, UVLO Current Limit, Thermal Shutdown, UVLO Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) Current Limit, Thermal Shutdown, UVLO Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) Current Limit, Thermal Shutdown, UVLO Current Limit, Thermal Shutdown, UVLO Current Limit, Thermal Shutdown, UVLO
Operating Temperature -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad
Supplier Device Package 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1)
