TLV71315PDQNR
  • Share:

Texas Instruments TLV71315PDQNR

Manufacturer No:
TLV71315PDQNR
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
TLV71315PDQNR Datasheet
ECAD Model:
-
Description:
IC REG LINEAR 1.5V 150MA 4X2SON
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Configuration:Positive
Output Type:Fixed
Number of Regulators:1
Voltage - Input (Max):5.5V
Voltage - Output (Min/Fixed):1.5V
Voltage - Output (Max):-
Voltage Dropout (Max):1.02V @ 150mA
Current - Output:150mA
Current - Quiescent (Iq):75 µA
Current - Supply (Max):-
PSRR:70dB ~ 55dB (100Hz ~ 1MHz)
Control Features:Enable
Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature:-40°C ~ 125°C (TJ)
Mounting Type:Surface Mount
Package / Case:4-XDFN Exposed Pad
Supplier Device Package:4-X2SON (1x1)
0 Remaining View Similar

In Stock

$0.12
7,190

Please send RFQ , we will respond immediately.

Similar Products

Part Number TLV71315PDQNR TLV71325PDQNR   TLV71315PDQNT   TLV71318PDQNR   TLV73315PDQNR   TLV713185PDQNR   TLV71715PDQNR   TLV71310PDQNR   TLV71312PDQNR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Active Active Active Active Active Active Active Active Active
Output Configuration Positive Positive Positive Positive Positive Positive Positive Positive Positive
Output Type Fixed Fixed Fixed Fixed Fixed Fixed Fixed Fixed Fixed
Number of Regulators 1 1 1 1 1 1 1 1 1
Voltage - Input (Max) 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V 5.5V
Voltage - Output (Min/Fixed) 1.5V 2.5V 1.5V 1.8V 1.5V 1.85V 1.5V 1V 1.2V
Voltage - Output (Max) - - - - - - - - -
Voltage Dropout (Max) 1.02V @ 150mA 0.57V @ 150mA 1.02V @ 150mA 0.7V @ 150mA 0.4V @ 300mA 0.7V @ 150mA 0.45V @ 150mA 1.02V @ 150mA 1.02V @ 150mA
Current - Output 150mA 150mA 150mA 150mA 300mA 150mA 150mA 150mA 150mA
Current - Quiescent (Iq) 75 µA 75 µA 75 µA 75 µA 60 µA 75 µA 55 µA 75 µA 75 µA
Current - Supply (Max) - - - - - - - - -
PSRR 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 55dB (100Hz ~ 1MHz) 68dB ~ 28dB (100Hz ~ 100kHz) 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 43dB (10Hz ~ 100kHz) 70dB ~ 55dB (100Hz ~ 1MHz) 70dB ~ 55dB (100Hz ~ 1MHz)
Control Features Enable Enable Enable Enable Enable Enable Enable Enable Enable
Protection Features Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO) Over Current, Over Temperature, Reverse Polarity, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 85°C (TJ) -40°C ~ 125°C (TJ) -40°C ~ 125°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad 4-XDFN Exposed Pad
Supplier Device Package 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1) 4-X2SON (1x1)
