| Part Number | TLC5949PWPR | TLC5929PWPR | TLC5940PWPR | TLC5941PWPR | TLC5942PWPR | TLC5943PWPR | TLC5944PWPR | TLC5945PWPR | TLC5946PWPR | TLC5948PWPR | TLC5949PWP |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Active | Discontinued at Digi-Key | Active | Active | Active | Active | Active | Active |
| Type | Linear | Linear | Linear | Linear | Linear | Linear | Linear | Linear | Linear | - | Linear |
| Topology | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register | Shift Register | - | Shift Register |
| Internal Switch(s) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | - | Yes |
| Number of Outputs | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | - | 16 |
| Voltage - Supply (Min) | 3V | 3V | 3V | 3V | 3V | 3V | 3V | 3V | 3V | - | 3V |
| Voltage - Supply (Max) | 3.6V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | 5.5V | - | 3.6V |
| Voltage - Output | 10V | 10V | 17V | 17V | 17V | 17V | 3V ~ 15V | 17V | 17V | - | 10V |
| Current - Output / Channel | 45mA | 50mA | 120mA | 80mA | 50mA | 50mA | 60mA | 80mA | 40mA | - | 45mA |
| Frequency | 33MHz | 20MHz | 30MHz | - | 30MHz | 30MHz | 30MHz | 30MHz | - | - | 33MHz |
| Dimming | PWM | - | - | - | - | - | - | - | - | - | PWM |
| Applications | Signage | Signage | Backlight | Backlight, Signage | Backlight | Backlight | Signage | Backlight | Backlight, Signage | - | Signage |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | - | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | - | Surface Mount |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | 28-PowerTSSOP (0.173", 4.40mm Width) | - | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 24-HTSSOP | 24-HTSSOP | 28-HTSSOP | 28-HTSSOP | 28-HTSSOP | 28-HTSSOP | 28-HTSSOP | 28-HTSSOP | 28-HTSSOP | - | 24-HTSSOP |
