| Part Number | TLC2654MLB | TLC2652MLB |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| Amplifier Type | Chopper (Zero-Drift) | Chopper (Zero-Drift) |
| Number of Circuits | 1 | 1 |
| Output Type | - | - |
| Slew Rate | 2.9V/µs | 3.1V/µs |
| Gain Bandwidth Product | 1.9 MHz | 1.9 MHz |
| -3db Bandwidth | - | - |
| Current - Input Bias | 50 pA | 4 pA |
| Voltage - Input Offset | 5 mV | 0.6 µV |
| Current - Supply | 1.5mA | 1.5mA |
| Current - Output / Channel | 50 mA | 50 mA |
| Voltage - Supply Span (Min) | 4.6 V | 3.8 V |
| Voltage - Supply Span (Max) | 16 V | 16 V |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | TO-99-8 Metal Can | TO-99-8 Metal Can |
| Supplier Device Package | TO-99-8 | TO-99-8 |
