| Part Number | TLC2272AQDRG4 | TLC2272QDRG4 | TLC2274AQDRG4 | TLC2262AQDRG4 | TLC2272ACDRG4 | TLC2272AIDRG4 | TLC2272AMDRG4 | TLC2272AQDG4 |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Amplifier Type | CMOS | CMOS | General Purpose | CMOS | CMOS | CMOS | CMOS | CMOS |
| Number of Circuits | 2 | 2 | 4 | 2 | 2 | 2 | 2 | 2 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 3.6V/µs | 3.6V/µs | 3.6V/µs | 0.55V/µs | 3.6V/µs | 3.6V/µs | 3.6V/µs | 3.6V/µs |
| Gain Bandwidth Product | 2.25 MHz | 2.25 MHz | 2.25 MHz | 730 kHz | 2.25 MHz | 2.25 MHz | 2.25 MHz | 2.25 MHz |
| -3db Bandwidth | - | - | - | - | - | - | - | - |
| Current - Input Bias | 1 pA | 1 pA | 1 pA | 1 pA | 1 pA | 1 pA | 1 pA | 1 pA |
| Voltage - Input Offset | 300 µV | 300 µV | 300 µV | 300 µV | 300 µV | 300 µV | 300 µV | 300 µV |
| Current - Supply | 2.4mA (x2 Channels) | 2.4mA (x2 Channels) | 4.8mA (x4 Channels) | 425µA (x2 Channels) | 2.4mA (x2 Channels) | 2.4mA (x2 Channels) | 2.4mA (x2 Channels) | 2.4mA (x2 Channels) |
| Current - Output / Channel | 50 mA | 50 mA | 50 mA | 50 mA | 50 mA | 50 mA | 50 mA | 50 mA |
| Voltage - Supply Span (Min) | 4.4 V | 4.4 V | 4.4 V | 4.4 V | 4.4 V | 4.4 V | 4.4 V | 4.4 V |
| Voltage - Supply Span (Max) | 16 V | 16 V | 16 V | 16 V | 16 V | 16 V | 16 V | 16 V |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C | 0°C ~ 70°C (TA) | -40°C ~ 125°C (TA) | -55°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 14-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC | 8-SOIC | 14-SOIC | 8-SOIC | 8-SOIC | 8-SOIC | 8-SOIC | 8-SOIC |
