| Part Number | TL594CNE4 | TL594CNG4 | TL594CDE4 |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Discontinued at Digi-Key | Active |
| Output Type | - | Transistor Driver | Transistor Driver |
| Function | - | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Down, Step-Up/Step-Down |
| Output Configuration | - | Positive | Positive |
| Topology | - | Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull | Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull |
| Number of Outputs | - | 2 | 2 |
| Output Phases | - | 1 | 1 |
| Voltage - Supply (Vcc/Vdd) | - | 7V ~ 40V | 7V ~ 40V |
| Frequency - Switching | - | 1kHz ~ 300kHz | 1kHz ~ 300kHz |
| Duty Cycle (Max) | - | 97% | 97% |
| Synchronous Rectifier | - | No | No |
| Clock Sync | - | No | No |
| Serial Interfaces | - | - | - |
| Control Features | - | Dead Time Control, Frequency Control | Dead Time Control, Frequency Control |
| Operating Temperature | - | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | - | Through Hole | Surface Mount |
| Package / Case | - | 16-DIP (0.300", 7.62mm) | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | - | 16-PDIP | 16-SOIC |
