| Part Number | TL431CPK | TL431IPK | TL431QPK | TL431CPS | TL431CPW | TL431CP | TL431CPG |
|---|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | onsemi |
| Product Status | Active | Active | Active | Active | Obsolete | Active | Obsolete |
| Reference Type | Shunt | Shunt | Shunt | Shunt | Shunt | Shunt | Shunt |
| Output Type | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable | Adjustable |
| Voltage - Output (Min/Fixed) | 2.495V | 2.495V | 2.495V | 2.495V | 2.495V | 2.495V | 2.495V |
| Voltage - Output (Max) | 36 V | 36 V | 36 V | 36 V | 36 V | 36 V | 36 V |
| Current - Output | 100 mA | 100 mA | 100 mA | 100 mA | 100 mA | 100 mA | 100 mA |
| Tolerance | ±2.2% | ±2.2% | ±2.2% | ±2% | ±2.2% | ±2.2% | ±2.2% |
| Temperature Coefficient | - | - | - | - | - | - | 50ppm/°C Typical |
| Noise - 0.1Hz to 10Hz | - | - | - | - | - | - | - |
| Noise - 10Hz to 10kHz | - | - | - | - | - | - | - |
| Voltage - Input | - | - | - | - | - | - | - |
| Current - Supply | - | - | - | - | - | - | - |
| Current - Cathode | 1 mA | 1 mA | 1 mA | 1 mA | 1 mA | 1 mA | 1 mA |
| Operating Temperature | 0°C ~ 70°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole | Through Hole |
| Package / Case | TO-243AA | TO-243AA | TO-243AA | 8-SOIC (0.209", 5.30mm Width) | 8-TSSOP (0.173", 4.40mm Width) | 8-DIP (0.300", 7.62mm) | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | SOT-89-3 | SOT-89-3 | SOT-89-3 | 8-SO | 8-TSSOP | 8-PDIP | 8-PDIP |
