| Part Number | SN74S00NSRE4 | SN74S00PSRE4 | SN74S08NSRE4 | SN74S10NSRE4 | SN74S00NSRG4 |
|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Logic Type | NAND Gate | NAND Gate | AND Gate | NAND Gate | NAND Gate |
| Number of Circuits | 4 | 2 | 4 | 3 | 4 |
| Number of Inputs | 2 | 2 | 2 | 3 | 2 |
| Features | - | - | - | - | - |
| Voltage - Supply | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V |
| Current - Quiescent (Max) | - | - | - | - | - |
| Current - Output High, Low | 1mA, 20mA | 1mA, 20mA | 1mA, 20mA | 1mA, 20mA | 1mA, 20mA |
| Logic Level - Low | 0.8V | 0.8V | 0.8V | 0.8V | 0.8V |
| Logic Level - High | 2V | 2V | 2V | 2V | 2V |
| Max Propagation Delay @ V, Max CL | 5ns @ 5V, 50pF | 5ns @ 5V, 50pF | 7.5ns @ 5V, 50pF | 5ns @ 5V, 50pF | 5ns @ 5V, 50pF |
| Operating Temperature | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 14-SO | 8-SO | 14-SO | 14-SO | 14-SO |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) | 8-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) |
