| Part Number | SN74HCT00ANS | SN74HCT00NS | SN74HCT02ANS | SN74HCT08ANS | SN74HCT00ANSR |
|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Active | Active | Active | Obsolete |
| Logic Type | NAND Gate | NAND Gate | NOR Gate | NOR Gate | NAND Gate |
| Number of Circuits | 4 | 4 | 2 | 2 | 4 |
| Number of Inputs | 2 | 2 | 4 | 4 | 2 |
| Features | - | - | - | - | - |
| Voltage - Supply | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 2V ~ 6V | 2V ~ 6V | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 2 µA | 2 µA | 2 µA | 2 µA | 2 µA |
| Current - Output High, Low | 4mA, 4mA | 4mA, 4mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 4mA, 4mA |
| Logic Level - Low | 0.8V | 0.8V | 0.8V | 0.8V | 0.8V |
| Logic Level - High | 2V | 2V | 2V | 2V | 2V |
| Max Propagation Delay @ V, Max CL | 18ns @ 5.5V, 50pF | 18ns @ 5.5V, 50pF | 20ns @ 6V, 50pF | 20ns @ 6V, 50pF | 18ns @ 5.5V, 50pF |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -55°C ~ 125°C | -55°C ~ 125°C | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 14-SO | 14-SO | 14-SO | 14-SO | 14-SO |
| Package / Case | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.209", 5.30mm Width) |
