| Part Number | SN74HC4852DGVR | SN74HC4851DGVR |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| Switch Circuit | SP4T | - |
| Multiplexer/Demultiplexer Circuit | 4:1 | 8:1 |
| Number of Circuits | 2 | 1 |
| On-State Resistance (Max) | 195Ohm | 195Ohm |
| Channel-to-Channel Matching (ΔRon) | 3Ohm | 3Ohm |
| Voltage - Supply, Single (V+) | 2V ~ 6V | 2V ~ 6V |
| Voltage - Supply, Dual (V±) | - | - |
| Switch Time (Ton, Toff) (Max) | 39ns, 78ns | 78ns, 78ns |
| -3db Bandwidth | - | - |
| Charge Injection | - | - |
| Channel Capacitance (CS(off), CD(off)) | 22pF | 22pF |
| Current - Leakage (IS(off)) (Max) | 200nA | 200nA |
| Crosstalk | - | - |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 16-TFSOP (0.173", 4.40mm Width) | 16-TFSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TVSOP | 16-TVSOP |
