| Part Number | SN74HC00ADBR | SN74HC00DBR |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| Logic Type | NAND Gate | NAND Gate |
| Number of Circuits | 4 | 4 |
| Number of Inputs | 2 | 2 |
| Features | - | - |
| Voltage - Supply | 2V ~ 6V | 2V ~ 6V |
| Current - Quiescent (Max) | 2 µA | 2 µA |
| Current - Output High, Low | 5.2mA, 5.2mA | 5.2mA, 5.2mA |
| Logic Level - Low | 0.1V ~ 0.26V | 0.5V ~ 1.8V |
| Logic Level - High | 1.9V ~ 5.9V | 1.5V ~ 4.2V |
| Max Propagation Delay @ V, Max CL | 13ns @ 6V, 50pF | 15ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 14-SSOP | 14-SSOP |
| Package / Case | 14-SSOP (0.209", 5.30mm Width) | 14-SSOP (0.209", 5.30mm Width) |
