SN74ALVCH16821DLR
  • Share:

Texas Instruments SN74ALVCH16821DLR

Manufacturer No:
SN74ALVCH16821DLR
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
SN74ALVCH16821DLR Datasheet
ECAD Model:
-
Description:
IC FF D-TYPE DUAL 10BIT 56SSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Function:Standard
Type:D-Type
Output Type:Tri-State, Non-Inverted
Number of Elements:2
Number of Bits per Element:10
Clock Frequency:150 MHz
Max Propagation Delay @ V, Max CL:4.5ns @ 3.3V, 50pF
Trigger Type:Positive Edge
Current - Output High, Low:24mA, 24mA
Voltage - Supply:1.65V ~ 3.6V
Current - Quiescent (Iq):40 µA
Input Capacitance:3.5 pF
Operating Temperature:-40°C ~ 85°C (TA)
Mounting Type:Surface Mount
Supplier Device Package:56-SSOP
Package / Case:56-BSSOP (0.295", 7.50mm Width)
0 Remaining View Similar

In Stock

$1.93
307

Please send RFQ , we will respond immediately.

Similar Products

Part Number SN74ALVCH16821DLR SN74ALVCH16823DLR   SN74ALVTH16821DLR   SN74ALVCH16721DLR   SN74ALVCH16820DLR   SN74ALVCH16821DL
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Product Status Discontinued at Digi-Key Active Active Active Obsolete Active
Function Standard Master Reset Standard Standard Standard Standard
Type D-Type D-Type D-Type D-Type D-Type D-Type
Output Type Tri-State, Non-Inverted Tri-State, Non-Inverted Tri-State, Non-Inverted Tri-State, Non-Inverted Tri-State, Non-Inverted Tri-State, Non-Inverted
Number of Elements 2 2 2 1 1 2
Number of Bits per Element 10 9 10 20 10 10
Clock Frequency 150 MHz 150 MHz 150 MHz 150 MHz 150 MHz 150 MHz
Max Propagation Delay @ V, Max CL 4.5ns @ 3.3V, 50pF 4.5ns @ 3.3V, 30pF 3.5ns @ 3.3V, 50pF 4.3ns @ 3.3V, 30pF 4.8ns @ 3.3V, 50pF 4.5ns @ 3.3V, 50pF
Trigger Type Positive Edge Positive Edge Positive Edge Positive Edge Positive Edge Positive Edge
Current - Output High, Low 24mA, 24mA 24mA, 24mA 8mA, 24mA; 32mA, 64mA 24mA, 24mA 24mA, 24mA 24mA, 24mA
Voltage - Supply 1.65V ~ 3.6V 1.65V ~ 3.6V 2.3V ~ 2.7V, 3V ~ 3.6V 1.65V ~ 3.6V 1.65V ~ 3.6V 1.65V ~ 3.6V
Current - Quiescent (Iq) 40 µA 40 µA 100 µA 40 µA 40 µA 40 µA
Input Capacitance 3.5 pF 4.5 pF 3.5 pF 3.5 pF 3.5 pF 3.5 pF
Operating Temperature -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA) -40°C ~ 85°C (TA)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Supplier Device Package 56-SSOP 56-SSOP 56-SSOP 56-SSOP 56-SSOP 56-SSOP
Package / Case 56-BSSOP (0.295", 7.50mm Width) 56-BSSOP (0.295", 7.50mm Width) 56-BSSOP (0.295", 7.50mm Width) 56-BSSOP (0.295", 7.50mm Width) 56-BSSOP (0.295", 7.50mm Width) 56-BSSOP (0.295", 7.50mm Width)
