Texas Instruments-PT5109L - DC DC Converters Product Specifications and Latest Quotes

Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	9.6V
Voltage - Input (Max):	38V
Voltage - Output 1:	5.6V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	5 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	90%
Mounting Type:	Surface Mount
Package / Case:	3-SMD Module
Size / Dimension:	1.02" L x 1.00" W x 0.38" H (25.9mm x 25.4mm x 9.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Texas Instruments PT5109L
