| Part Number | OPA2320AIDRGT | OPA2322AIDRGT | OPA2320AIDRGR |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active |
| Amplifier Type | CMOS | CMOS | CMOS |
| Number of Circuits | 2 | 2 | 2 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 10V/µs | 10V/µs | 10V/µs |
| Gain Bandwidth Product | 20 MHz | 20 MHz | 20 MHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 0.2 pA | 0.2 pA | 0.2 pA |
| Voltage - Input Offset | 40 µV | 500 µV | 40 µV |
| Current - Supply | 1.45mA | 1.6mA (x2 Channels) | 1.45mA |
| Current - Output / Channel | 65 mA | 65 mA | 65 mA |
| Voltage - Supply Span (Min) | 1.8 V | 1.8 V | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V | 5.5 V | 5.5 V |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad | 8-WFDFN Exposed Pad | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-SON (3x3) | 8-SON (3x3) | 8-SON (3x3) |
