| Part Number | LP3995ILDX-1.6 | LP3995ILD-1.6 | LP3995ILDX-1.5 |
|---|---|---|---|
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments |
| Product Status | Obsolete | Active | Obsolete |
| Output Configuration | Positive | - | Positive |
| Output Type | Fixed | - | Fixed |
| Number of Regulators | 1 | - | 1 |
| Voltage - Input (Max) | 6V | - | 6V |
| Voltage - Output (Min/Fixed) | 1.6V | - | 1.5V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.1V @ 150mA | - | 0.1V @ 150mA |
| Current - Output | 150mA | - | 150mA |
| Current - Quiescent (Iq) | 150 µA | - | 150 µA |
| Current - Supply (Max) | 200 µA | - | 200 µA |
| PSRR | 60dB ~ 50dB (1kHz ~ 10kHz) | - | 60dB ~ 50dB (1kHz ~ 10kHz) |
| Control Features | Enable | - | Enable |
| Protection Features | Over Temperature, Short Circuit | - | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C | - | -40°C ~ 125°C |
| Mounting Type | Surface Mount | - | Surface Mount |
| Package / Case | 6-WDFN Exposed Pad | - | 6-WDFN Exposed Pad |
| Supplier Device Package | 6-WSON (2.92x3.29) | - | 6-WSON (2.92x3.29) |
