| Part Number | LP3965ET-3.3 | LP3963ET-3.3 | LP3965ES-3.3 |
|---|---|---|---|
| Manufacturer | Texas Instruments | National Semiconductor | Texas Instruments |
| Product Status | Obsolete | Active | Not For New Designs |
| Output Configuration | Positive | - | Positive |
| Output Type | Fixed | - | Fixed |
| Number of Regulators | 1 | - | 1 |
| Voltage - Input (Max) | 7V | - | 7V |
| Voltage - Output (Min/Fixed) | 3.3V | - | 3.3V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.55V @ 1.5A | - | 0.55V @ 1.5A |
| Current - Output | 1.5A | - | 1.5A |
| Current - Quiescent (Iq) | 9 mA | - | 9 mA |
| Current - Supply (Max) | 15 mA | - | 15 mA |
| PSRR | - | - | - |
| Control Features | Enable | - | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit | - | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C | - | -40°C ~ 125°C |
| Mounting Type | Through Hole | - | Surface Mount |
| Package / Case | TO-220-5 Formed Leads | - | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA |
| Supplier Device Package | TO-220-5 | - | DDPAK/TO-263-5 |
