Please send RFQ , we will respond immediately.
| Part Number | LP2951-50DRGR | LP2951-30DRGR | LP2951-50DRG4 |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Discontinued at Digi-Key |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Adjustable (Fixed) | Adjustable (Fixed) | Adjustable (Fixed) |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 30V | 30V | 30V |
| Voltage - Output (Min/Fixed) | 1.235V (5V) | 1.235V (3V) | 1.235V (5V) |
| Voltage - Output (Max) | 30V | 30V | 30V |
| Voltage Dropout (Max) | 0.6V @ 100mA | 0.6V @ 100mA | 0.6V @ 100mA |
| Current - Output | 100mA | 100mA | 100mA |
| Current - Quiescent (Iq) | 120 µA | 120 µA | 120 µA |
| Current - Supply (Max) | 14 mA | 14 mA | 14 mA |
| PSRR | - | - | - |
| Control Features | Enable | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-WFDFN Exposed Pad | 8-WFDFN Exposed Pad | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SON (3x3) | 8-SON (3x3) | 8-SOIC |
