| Part Number | LMV981IDCKRE4 | LMV981IDCKRG4 | LMV931IDCKRE4 |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Obsolete | Obsolete |
| Amplifier Type | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 0.42V/µs | 0.42V/µs | 0.42V/µs |
| Gain Bandwidth Product | 1.5 MHz | 1.5 MHz | 1.5 MHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 15 nA | 15 nA | 15 nA |
| Voltage - Input Offset | 1 mV | 1 mV | 1 mV |
| Current - Supply | 116µA | 116µA | 116µA |
| Current - Output / Channel | - | - | - |
| Voltage - Supply Span (Min) | 1.8 V | 1.8 V | 1.8 V |
| Voltage - Supply Span (Max) | 5 V | 5 V | 5 V |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 | 6-TSSOP, SC-88, SOT-363 | 5-TSSOP, SC-70-5, SOT-353 |
| Supplier Device Package | SC-70-6 | SC-70-6 | SC-70-5 |
