| Part Number | LM60440DRPKR | LM60430DRPKR | LM60440ARPKR |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active |
| Function | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck |
| Output Type | Adjustable | Adjustable | Adjustable |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Input (Min) | 3.8V | 3.8V | 3.8V |
| Voltage - Input (Max) | 36V | 36V | 36V |
| Voltage - Output (Min/Fixed) | 1V | 1V | 1V |
| Voltage - Output (Max) | 24V | 24V | 24V |
| Current - Output | 4A | 3A | 4A |
| Frequency - Switching | 1MHz | 1MHz | 400kHz |
| Synchronous Rectifier | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank |
| Package / Case | 13-PowerWFQFN | 13-PowerWFQFN | 13-PowerWFQFN |
| Supplier Device Package | 13-WQFN-HR (3x2) | 13-WQFN-HR (3x2) | 13-WQFN-HR (3x2) |
