LM5026MTX
  • Share:

Texas Instruments LM5026MTX

Manufacturer No:
LM5026MTX
Manufacturer:
Texas Instruments
Package:
Tape & Reel (TR)
Datasheet:
LM5026MTX Datasheet
ECAD Model:
-
Description:
IC REG CTRLR FWRD CONV 16TSSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Output Type:Transistor Driver
Function:Step-Up/Step-Down
Output Configuration:Positive, Isolation Capable
Topology:Forward Converter
Number of Outputs:2
Output Phases:1
Voltage - Supply (Vcc/Vdd):8V ~ 15V
Frequency - Switching:200kHz ~ 590kHz
Duty Cycle (Max):70%, 80%
Synchronous Rectifier:No
Clock Sync:Yes
Serial Interfaces:-
Control Features:Dead Time Control, Frequency Control, Reset, Soft Start
Operating Temperature:-40°C ~ 125°C (TJ)
Mounting Type:Surface Mount
Package / Case:16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package:16-TSSOP
