Please send RFQ , we will respond immediately.
| Part Number | LM358BP | LM358P | LM358BPX | LM358AP |
|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Active | Discontinued at Digi-Key | Active |
| Amplifier Type | General Purpose | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 2 | 2 | 2 | 2 |
| Output Type | - | - | - | - |
| Slew Rate | 0.5V/µs | 0.3V/µs | 0.5V/µs | 0.3V/µs |
| Gain Bandwidth Product | 1.2 MHz | 700 kHz | 1.2 MHz | 700 kHz |
| -3db Bandwidth | - | - | - | - |
| Current - Input Bias | 10 nA | 20 nA | 10 nA | 15 nA |
| Voltage - Input Offset | 1 mV | 3 mV | 1 mV | 2 mV |
| Current - Supply | 300µA (x2 Channels) | 500µA (x2 Channels) | 300µA (x2 Channels) | 500µA (x2 Channels) |
| Current - Output / Channel | 40 mA | 40 mA | 40 mA | 40 mA |
| Voltage - Supply Span (Min) | 3 V | 3 V | 3 V | 3 V |
| Voltage - Supply Span (Max) | 30 V | 30 V | 30 V | 30 V |
| Operating Temperature | -40°C ~ 85°C (TA) | 0°C ~ 70°C (TA) | -40°C ~ 85°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount | Through Hole | Surface Mount | Through Hole |
| Package / Case | 8-VFBGA | 8-DIP (0.300", 7.62mm) | 8-VFBGA | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-uSMD | 8-PDIP | 8-uSMD | 8-PDIP |
