| Part Number | LM2750LD-ADJ | LM2750LDX-ADJ | LM2750SD-ADJ |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Obsolete | Obsolete |
| Function | Step-Up | Step-Up | Step-Up |
| Output Configuration | Positive | Positive | Positive |
| Topology | Charge Pump | Charge Pump | Charge Pump |
| Output Type | Adjustable | Adjustable | Adjustable |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Input (Min) | 2.7V | 2.7V | 2.7V |
| Voltage - Input (Max) | 5.6V | 5.6V | 5.6V |
| Voltage - Output (Min/Fixed) | 3.8V | 3.8V | 3.8V |
| Voltage - Output (Max) | 5.2V | 5.2V | 5.2V |
| Current - Output | 120mA | 120mA | 120mA |
| Frequency - Switching | 1.7MHz | 1.7MHz | 1.7MHz |
| Synchronous Rectifier | No | No | No |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad | 10-WFDFN Exposed Pad | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-WSON (3x3) | 10-WSON (3x3) | 10-WSON (3x3) |
