| Part Number | LF398H | LF398P | LF398M | LF398N | LF198H | LF298H |
|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Not For New Designs | Obsolete | Active | Active |
| Amplifier Type | Sample and Hold | Sample and Hold | Sample and Hold | Sample and Hold | Sample and Hold | Sample and Hold |
| Number of Circuits | 1 | 1 | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - | - | - |
| Slew Rate | - | - | - | - | - | - |
| Gain Bandwidth Product | - | - | - | - | - | - |
| -3db Bandwidth | - | - | - | - | - | - |
| Current - Input Bias | 10 nA | 10 nA | 10 nA | 10 nA | 5 nA | 5 nA |
| Voltage - Input Offset | 2 mV | 2 mV | 2 mV | 2 mV | 1 mV | 1 mV |
| Current - Supply | 4.5mA | 4.5mA | 4.5mA | 4.5mA | 4.5mA | 4.5mA |
| Current - Output / Channel | - | - | - | - | - | - |
| Voltage - Supply Span (Min) | 10 V | 10 V | 10 V | 10 V | 10 V | 10 V |
| Voltage - Supply Span (Max) | 36 V | 36 V | 36 V | 36 V | 36 V | 36 V |
| Operating Temperature | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | -55°C ~ 125°C | -25°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole | Surface Mount | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-99-8 Metal Can | 8-DIP (0.300", 7.62mm) | 14-SOIC (0.154", 3.90mm Width) | 8-DIP (0.300", 7.62mm) | TO-99-8 Metal Can | TO-99-8 Metal Can |
| Supplier Device Package | TO-99-8 | 8-PDIP | 14-SOIC | 8-PDIP | TO-99-8 | TO-99-8 |
