| Part Number | F280023PMSR | F280023PNSR | F280023PTSR | F280023CPMSR | F280023PMQR |
|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Active | Active |
| Core Processor | C28x | C28x | C28x | C28x | C28x |
| Core Size | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| Speed | 100MHz | 100MHz | 100MHz | 100MHz | 100MHz |
| Connectivity | CANbus, I²C, LINbus, SCI, SPI, UART/USART | CANbus, I²C, LINbus, SCI, SPI, UART/USART | CANbus, I²C, LINbus, SCI, SPI, UART/USART | CANbus, I²C, LINbus, SCI, SPI, UART/USART | CANbus, I²C, LINbus, SCI, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 26 | 39 | 14 | 26 | 26 |
| Program Memory Size | 64KB (32K x 16) | 64KB (32K x 16) | 64KB (32K x 16) | 64KB (32K x 16) | 64KB (32K x 16) |
| Program Memory Type | Flash | Flash | Flash | Flash | Flash |
| EEPROM Size | - | - | - | - | - |
| RAM Size | 12K x 16 | 12K x 16 | 12K x 16 | 12K x 16 | 12K x 16 |
| Voltage - Supply (Vcc/Vdd) | 2.81V ~ 3.63V | 2.81V ~ 3.63V | 2.81V ~ 3.63V | 2.81V ~ 3.63V | 2.81V ~ 3.63V |
| Data Converters | A/D 16x12b; D/A 2x12b | A/D 16x12b; D/A 2x12b | A/D 14x12b; D/A 2x12b | A/D 16x12b; D/A 2x12b | A/D 16x12b; D/A 2x12b |
| Oscillator Type | Internal | Internal | Internal | Internal | Internal |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 64-LQFP | 80-LQFP | 48-LQFP | 64-LQFP | 64-LQFP |
| Supplier Device Package | 64-LQFP (10x10) | 80-LQFP (12x12) | 48-LQFP (7x7) | 64-LQFP (10x10) | 64-LQFP (10x10) |
