Please send RFQ , we will respond immediately.
| Part Number | CY74FCT374ATQCT | CY74FCT374TQCT | CY74FCT574ATQCT | CY74FCT377ATQCT | CY74FCT374CTQCT | CY74FCT2374ATQCT |
|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Active | Active | Discontinued at Digi-Key | Obsolete |
| Function | Standard | Standard | Standard | Standard | Standard | Standard |
| Type | D-Type | D-Type | D-Type | D-Type | D-Type | D-Type |
| Output Type | Tri-State, Non-Inverted | Tri-State, Non-Inverted | Tri-State, Non-Inverted | Non-Inverted | Tri-State, Non-Inverted | Tri-State, Non-Inverted |
| Number of Elements | 1 | 1 | 1 | 1 | 1 | 1 |
| Number of Bits per Element | 8 | 8 | 8 | 8 | 8 | 8 |
| Clock Frequency | - | - | - | - | 250 MHz | 250 MHz |
| Max Propagation Delay @ V, Max CL | 6.2ns @ 50pF | 10ns @ 5V, 50pF | 6.2ns @ 50pF | 7.2ns @ 5V, 50pF | 5.2ns @ 5V, 50pF | 6.5ns @ 5V, 50pF |
| Trigger Type | Positive Edge | Positive Edge | Positive Edge | Positive Edge | Positive Edge | Positive Edge |
| Current - Output High, Low | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA | 15mA, 12mA |
| Voltage - Supply | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75 ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V |
| Current - Quiescent (Iq) | 200 µA | 200 µA | 200 µA | 200 µA | 200 µA | 200 µA |
| Input Capacitance | 5 pF | 5 pF | 5 pF | 5 pF | 5 pF | 5 pF |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 20-SSOP | 20-SSOP | 20-SSOP | 20-SSOP | 20-SSOP | 20-SSOP |
| Package / Case | 20-SSOP (0.154", 3.90mm Width) | 20-SSOP (0.154", 3.90mm Width) | 20-SSOP (0.154", 3.90mm Width) | 20-SSOP (0.154", 3.90mm Width) | 20-SSOP (0.154", 3.90mm Width) | 20-SSOP (0.154", 3.90mm Width) |
