| Part Number | CSD87355Q5DT | CSD87355Q5D |
|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments |
| Product Status | Active | Active |
| FET Type | 2 N-Channel (Dual) Asymmetrical | 2 N-Channel (Dual) Asymmetrical |
| FET Feature | Logic Level Gate, 5V Drive | Standard |
| Drain to Source Voltage (Vdss) | 30V | 30V |
| Current - Continuous Drain (Id) @ 25°C | 45A | - |
| Rds On (Max) @ Id, Vgs | - | - |
| Vgs(th) (Max) @ Id | 1.9V @ 250µA | 1.9V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 13.7nC @ 4.5V | 13.7nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1860pF @ 15V | 1860pF @ 15V |
| Power - Max | 2.8W | 12W |
| Operating Temperature | -55°C ~ 155°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 8-PowerLDFN | 8-PowerLDFN |
| Supplier Device Package | 8-LSON (5x6) | 8-LSON (5x6) |
