| Part Number | AWR2243ABGABLRQ1 | AWR2243APBGABLRQ1 | AWR2243ABGABLQ1 |
|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Obsolete | Active |
| Type | TxRx + MCU | TxRx + MCU | TxRx + MCU |
| RF Family/Standard | - | - | - |
| Protocol | - | - | - |
| Modulation | - | - | - |
| Frequency | 76GHz ~ 81GHz | 76GHz ~ 81GHz | 76GHz ~ 81GHz |
| Data Rate (Max) | 600Mbps | 600Mbps | 600Mbps |
| Power - Output | 13dBm | 13dBm | 13dBm |
| Sensitivity | - | - | - |
| Memory Size | - | - | - |
| Serial Interfaces | I²C, SPI | I²C, SPI | I²C, SPI |
| GPIO | 3 | 3 | 3 |
| Voltage - Supply | 1.71V ~ 1.9V, 3.135V ~ 3.465V | 1.71V ~ 1.9V, 3.135V ~ 3.465V | 1.71V ~ 1.9V, 3.135V ~ 3.465V |
| Current - Receiving | - | - | - |
| Current - Transmitting | - | - | - |
| Operating Temperature | -40°C ~ 140°C (TJ) | -40°C ~ 140°C (TJ) | -40°C ~ 140°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 161-LFBGA, FCBGA | 161-LFBGA, FCBGA | 161-LFBGA, FCBGA |
| Supplier Device Package | 161-FC/CSP (10.4x10.4) | 161-FC/CSP (10.4x10.4) | 161-FC/CSP (10.4x10.4) |
