Please send RFQ , we will respond immediately.
| Part Number | 3656KG | 3650KG | 3656AG | 3656BG | 3656HG | 3656JG |
|---|---|---|---|---|---|---|
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Active | Obsolete |
| Amplifier Type | Isolation | Isolation | Isolation | Isolation | Isolation | Isolation |
| Number of Circuits | 1 | 1 | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - | - | - |
| Slew Rate | 0.1V/µs | 1.2V/µs | 0.1V/µs | 0.1V/µs | 0.1V/µs | 0.1V/µs |
| Gain Bandwidth Product | - | - | - | - | - | - |
| -3db Bandwidth | 30 kHz | 15 kHz | 30 kHz | 30 kHz | 30 kHz | 30 kHz |
| Current - Input Bias | 100 nA | 10 nA | 100 nA | 100 nA | 100 nA | 100 nA |
| Voltage - Input Offset | 1 mV | 500 µV | 2 mV | 1 mV | 4 mV | 2 mV |
| Current - Supply | 14mA | 2.3mA | 14mA | 14mA | 14mA | 14mA |
| Current - Output / Channel | 5 mA | 5 mA | 5 mA | 5 mA | 5 mA | 5 mA |
| Voltage - Supply Span (Min) | 17 V | 16 V | 17 V | 17 V | 17 V | 17 V |
| Voltage - Supply Span (Max) | 32 V | 36 V | 32 V | 32 V | 32 V | 32 V |
| Operating Temperature | 0°C ~ 70°C | 0°C ~ 85°C | -25°C ~ 85°C | -25°C ~ 85°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | 20-CDIP (0.900", 22.86mm) | 32-CDIP (0.900", 22.86mm) | 20-CDIP (0.900", 22.86mm) | 20-CDIP (0.900", 22.86mm) | 20-CDIP (0.900", 22.86mm) | 20-CDIP (0.900", 22.86mm) |
| Supplier Device Package | 20-CDIP | 32-CDIP | 20-CDIP | 20-CDIP | 20-CDIP | 20-CDIP |
