T9AV5D22-24
  • Share:

TE Connectivity Potter & Brumfield Relays T9AV5D22-24

Manufacturer No:
T9AV5D22-24
Manufacturer:
TE Connectivity Potter & Brumfield Relays
Package:
Bulk
Datasheet:
T9AV5D22-24 Datasheet
ECAD Model:
-
Description:
RELAY GEN PURPOSE SPDT 20A 24V
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Mounting Type:Through Hole
Coil Voltage:24VDC
Contact Form:SPDT (1 Form C)
Contact Rating (Current):20 A
Switching Voltage:277VAC - Max
Coil Current:41.7 mA
Coil Type:Non Latching
Features:-
Termination Style:PC Pin, Quick Connect - 0.250" (6.3mm)
Seal Rating:Sealed - Flux Protection
Coil Insulation:Class F
Must Operate Voltage:18 VDC
Must Release Voltage:2.4 VDC
Operate Time:15 ms
Release Time:15 ms
Operating Temperature:-55°C ~ 85°C
Contact Material:Silver Cadmium Oxide (AgCdO)
Relay Type:General Purpose
0 Remaining View Similar

In Stock

-
252

Please send RFQ , we will respond immediately.
