SDT-S-109LMR,000 Image
×
Favorite
Compare
Add to RFQ
Share:
TE Connectivity Potter & Brumfield Relays SDT-S-109LMR,000
Manufacturer No:
SDT-S-109LMR,000
Manufacturer:
TE Connectivity Potter & Brumfield Relays
Package:
Tube
Datasheet:
SDT-S-109LMR,000 Datasheet
ECAD Model:
-
Description:
RELAY GEN PURPOSE SPST 5A 9V
Delivery:
Payment:
Product Attributes
Mounting Type:
Through Hole
Coil Voltage:
9VDC
Contact Form:
SPST-NO (1 Form A)
Contact Rating (Current):
5 A
Switching Voltage:
250VAC, 30VDC - Max
Coil Current:
27.8 mA
Coil Type:
Non Latching
Features:
-
Termination Style:
PC Pin
Seal Rating:
-
Coil Insulation:
Class E
Must Operate Voltage:
6.75 VDC
Must Release Voltage:
0.9 VDC
Operate Time:
15 ms
Release Time:
5 ms
Operating Temperature:
-30°C ~ 70°C
Contact Material:
Silver Tin Oxide (AgSnO)
Relay Type:
General Purpose
0
Remaining
View Similar
In Stock
UnitPrice:
$1.70
Quantity:
530
